Rapidox SF6 6100 Bench Gas Analyser

Product Information

The Rapidox SF6 6100 Bench gas analyser is designed for controlling and monitoring the quality of SF6 gas over a range of applications, including medium & high voltage gas insulated electrical equipment, SF6 gas purity tests, medical testing, manufacturing and laboratory-based research and development.

Exceptionally accurate and stable readings are achieved in simultaneous analysis and data-logging of SF6, SO2 and H2O (dew point) gases. Fully compatible with the Rapidox Gas Recovery Bag, a gas output nozzle allows for the analyser to be attached, ensuring that all SF6 gas is recovered.

Read More

Category:

Product Information

The Rapidox SF6 6100 Bench gas analyser is designed for controlling and monitoring the quality of SF6 gas over a range of applications, including medium & high voltage gas insulated electrical equipment, SF6 gas purity tests, medical testing, manufacturing and laboratory-based research and development.

The Rapidox SF6 6100 Bench analyser is available as a complete instrument with a swing carry handle or as a 19″ cabinet rack mount format for industrial applications. Options include a set of genuine DN8 and DN20 fittings with a stainless steel braided hose (self-sealing couplings) and a separate thermal printer.

An optional pump enables two modes of operation. For SF6 sources at atmospheric pressure or below, the pump is activated to draw a sample through the analyser. Alternatively, the pump can be deactivated when sampling SF6 from a pressurised gas compartment up to 10 bar on the inlet. Gas flow is regulated manually via a rotary knob on the fascia and displayed electronically on the screen.

Features

  • Rapid measurement response of 3-4 minutes at 20°C.
  • Low maintenance sensors.
  • Fully programmable alarm circuits.
  • Programmable analogue outputs.
  • RS232/RS485 communications and complete data-logging software.
  • Optional long-life variable speed sample pump.
  • Large back-lit LCD display.
  • Password protection.
  • Operates on any worldwide mains voltage (90-260VAC).
  • Compatible with industry standard gas recovery systems.
Array ( [0] => Array ( [title] => Rapidox-SF6-6100-Bench-D11-412 Technical-Datasheet [category] => Datasheet & Application Notes [file_type] => PDF [link] => https://www.cambridge-sensotec.co.uk/wp-content/uploads/2023/04/Rapidox-SF6-6100-Bench-D11-412-Technical-Specification.pdf ) )

Product Specification

Gas Range Accuracy Range
SF6 (Sulphur Hexafluoride)0-100%±0.5% full-scale accuracy
H2O (Dew Point)-60°C to +20°Cdp±2°Cdp accuracy of reading
SO2 (Sulphur Dioxide)0-100ppm to 0-2000ppm±2% full-scale reading
HF (Hydrogen Fluoride)0-10ppm or 0-20ppm±2% full-scale reading
CF4* (Tetrafluoromethane)0-80%±1% of reading
H2S (Hydrogen Sulphide)0-200ppm to 0-2000ppm±2% full-scale
CO (Carbon Monoxide)0-500ppm to 0-5000ppm±2% full-scale
O2 (Air Content)0-100%±5% full-scale based on oxygen component
